48V100Ah LiFeOP4 Battery Pack Manual
Enerbyte 48V 100Ah LiFePO4 Batteries are widely used in telecommunications base stations, UPS, renewable energy systems, etc.
1. Built-in BMS designed as deep cycle battery energy storage system.
2. Long service life and high durability.
3. Light weight, standard size and space saving.
4. Supporting communication protocols RS232, RS485, CAN.
5. Maintenance-free.
6. Supporting parallel connection to increase capacity.
7. A-Grade top quality battery cells.
| Model | LFP48100(48V100Ah) |
| Nominal voltage | 48V |
| Nominal capacity | 100Ah |
| Combination mode | 15sets |
| Dimensions W×D×H (mm) | 482(442)×420×155 |
| Weight | About 38.5KG |
| Working voltage | 40.5-55V |
| Charging voltage | 54.5V |
| Charging current limiting | 20A(The default charging current is greater than 55A, and the current limiting is on) |
| Standard charging current current | 20A(0.2C) |
| Maximum continuous charging current | 50A(0.5C) |
| Standard discharge current | 20A (0.2C) |
| Maximum continuous discharge current | 100A (1.0C) |
| Charging temperature range | 0~50 ºC |
| Discharge temperature range | -20~60ºC |
| Monitoring communications | RS485-2,RS485-1,CAN |
| Number of cycles | 3000 times |
| Working environment | Humidity :≤95; Altitude :≤4000 |
